优化客服智能体的成本与质量（上）

pip install --upgrade openai pandas matplotlib jinja2 ipykernel

export OPENAI_API_KEY=...
export RUN_LIVE_API_CALLS=true

import json
import math
import os

os.environ.setdefault("MPLCONFIGDIR", "/tmp/matplotlib")

import matplotlib.pyplot as plt
import pandas as pd
from IPython.display import display
from openai import OpenAI

RUN_LIVE_API_CALLS = os.environ.get("RUN_LIVE_API_CALLS", "false").lower() == "true"
RUN_LLM_JUDGE = os.environ.get("RUN_LLM_JUDGE", "false").lower() == "true"
if (RUN_LIVE_API_CALLS or RUN_LLM_JUDGE) and not os.environ.get("OPENAI_API_KEY"):
    raise RuntimeError("Set OPENAI_API_KEY before enabling the live agent or judge.")
client = OpenAI() if RUN_LIVE_API_CALLS else None
judge_client = OpenAI() if RUN_LLM_JUDGE else None

pd.set_option("display.max_columns", 40)
pd.set_option("display.width", 140)
print("RUN_LIVE_API_CALLS =", RUN_LIVE_API_CALLS)
print("RUN_LLM_JUDGE =", RUN_LLM_JUDGE)

RUN_LIVE_API_CALLS = True
RUN_LLM_JUDGE = True

from support import EVAL_SET

pd.DataFrame(EVAL_SET)[
    [
        "ticket_id",
        "intent",
        "risk",
        "difficulty",
        "expected_tools",
        "expected_action",
        "must_escalate",
    ]
]

from support import lookup_order

# Inspect the decision-critical fields returned by the slim payload.
print(json.dumps(lookup_order("O-1001", payload="slim"), indent=2))

{
  "found": true,
  "order_id": "O-1001",
  "status": "in_transit",
  "carrier": "UPS",
  "eta": "tomorrow",
  "delivered_days_ago": null,
  "payment_status": "paid_once",
  "item_value": 18.0,
  "events": [
    "regional_delay"
  ]
}

from support import SLIM_TOOLS, VERBOSE_TOOLS, allowed_tool_choice

print("Verbose tool schema tokens:", math.ceil(len(json.dumps(VERBOSE_TOOLS)) / 4))
print("Slim tool schema tokens:", math.ceil(len(json.dumps(SLIM_TOOLS)) / 4))

Verbose tool schema tokens: 550
Slim tool schema tokens: 397

flowchart LR
    A["客户消息"] --> B["最强模型上的一个通用智能体"]
    B --> C["客户查询"]
    B --> D["订单查询"]
    B --> E["政策查询"]
    B --> F["退款或升级工具"]
    B --> G["客户回复"]
    B --> H["质量保证摘要"]
    B --> I["分析打标"]
    B --> J["路由审计"]

from support import CONTROLLED_PROMPT

print(CONTROLLED_PROMPT)

Role: E-commerce support assistant.

Goal: Resolve routine support tickets with the fewest necessary tool calls while preserving policy correctness.

Tool rules:
- Use only tools required for the current decision.
- Order status: order lookup only.
- Damaged delivery or refund: order lookup plus the relevant policy.
- Billing duplicate charge: order lookup plus billing policy, then escalate.
- Account access with unverified identity: customer lookup plus account policy, then escalate.

Response rules:
- Give the customer the outcome and next step.
- Do not expose internal reasoning, raw tool data, audit notes, or policy text.
- Keep the customer-facing answer under 120 words unless escalation legally requires more detail.

from simulation import MODEL_PRICES_USD_PER_1M

pd.DataFrame(MODEL_PRICES_USD_PER_1M).T.rename_axis("model")

from simulation import CACHE_FRIENDLY_PROMPT, VARIANT_ORDER, simulate_trace

traces = pd.DataFrame(
    simulate_trace(ticket, variant)
    for variant in VARIANT_ORDER
    for ticket in EVAL_SET
)
traces.drop(columns="tool_results").head()

summary = (
    traces.groupby(["variant", "variant_label"], sort=False)
    .agg(
        tickets=("ticket_id", "count"),
        mean_quality=("quality_score", "mean"),
        policy_compliance=("policy_compliant", "mean"),
        action_accuracy=("action_correct", "mean"),
        escalation_accuracy=("escalation_correct", "mean"),
        concise_rate=("concise", "mean"),
        mean_tool_calls=("tool_calls", "mean"),
        mean_extra_tool_calls=("extra_tool_calls", "mean"),
        mean_input_tokens=("input_tokens", "mean"),
        mean_cached_tokens=("cached_tokens", "mean"),
        mean_output_tokens=("output_tokens", "mean"),
        mean_reasoning_tokens=("reasoning_tokens", "mean"),
        mean_sync_tokens=("sync_tokens", "mean"),
        mean_total_tokens=("total_tokens", "mean"),
        p50_latency_s=("latency_s", "median"),
        p95_latency_s=("latency_s", lambda s: s.quantile(0.95)),
        sync_cost_per_ticket_usd=("sync_cost_usd", "mean"),
        background_cost_per_ticket_usd=("background_cost_usd", "mean"),
        cost_per_ticket_usd=("cost_usd", "mean"),
    )
    .reset_index()
)

baseline_cost = summary.loc[summary["variant"] == "00_bad_baseline", "cost_per_ticket_usd"].iloc[0]
baseline_tokens = summary.loc[summary["variant"] == "00_bad_baseline", "mean_total_tokens"].iloc[0]
baseline_latency = summary.loc[summary["variant"] == "00_bad_baseline", "p50_latency_s"].iloc[0]

summary["cost_reduction_vs_baseline"] = 1 - summary["cost_per_ticket_usd"] / baseline_cost
summary["token_reduction_vs_baseline"] = 1 - summary["mean_total_tokens"] / baseline_tokens
summary["latency_reduction_vs_baseline"] = 1 - summary["p50_latency_s"] / baseline_latency
summary["monthly_cost_at_100k_tickets"] = summary["cost_per_ticket_usd"] * 100_000

summary_view = summary[
    [
        "variant_label",
        "mean_quality",
        "policy_compliance",
        "action_accuracy",
        "escalation_accuracy",
        "mean_tool_calls",
        "mean_extra_tool_calls",
        "mean_sync_tokens",
        "mean_total_tokens",
        "mean_cached_tokens",
        "p50_latency_s",
        "cost_per_ticket_usd",
        "cost_reduction_vs_baseline",
        "monthly_cost_at_100k_tickets",
    ]
]

display(
    summary_view.style.format(
        {
            "mean_quality": "{:.2f}",
            "policy_compliance": "{:.0%}",
            "action_accuracy": "{:.0%}",
            "escalation_accuracy": "{:.0%}",
            "mean_tool_calls": "{:.1f}",
            "mean_extra_tool_calls": "{:.1f}",
            "mean_sync_tokens": "{:,.0f}",
            "mean_total_tokens": "{:,.0f}",
            "mean_cached_tokens": "{:,.0f}",
            "p50_latency_s": "{:.2f}",
            "cost_per_ticket_usd": "${:.5f}",
            "cost_reduction_vs_baseline": "{:.0%}",
            "monthly_cost_at_100k_tickets": "${:,.0f}",
        }
    )
)

round_impact = summary[
    [
        "variant_label",
        "mean_quality",
        "policy_compliance",
        "mean_tool_calls",
        "mean_extra_tool_calls",
        "mean_sync_tokens",
        "mean_total_tokens",
        "mean_cached_tokens",
        "p50_latency_s",
        "cost_per_ticket_usd",
    ]
].copy()

for col in ["mean_sync_tokens", "mean_total_tokens", "p50_latency_s", "cost_per_ticket_usd"]:
    round_impact[f"{col}_delta_vs_previous"] = round_impact[col].diff()

round_impact["quality_delta_vs_previous"] = round_impact["mean_quality"].diff()

display(
    round_impact.style.format(
        {
            "mean_quality": "{:.2f}",
            "policy_compliance": "{:.0%}",
            "mean_tool_calls": "{:.1f}",
            "mean_extra_tool_calls": "{:.1f}",
            "mean_sync_tokens": "{:,.0f}",
            "mean_total_tokens": "{:,.0f}",
            "mean_cached_tokens": "{:,.0f}",
            "p50_latency_s": "{:.2f}",
            "cost_per_ticket_usd": "${:.5f}",
            "mean_sync_tokens_delta_vs_previous": "{:+,.0f}",
            "mean_total_tokens_delta_vs_previous": "{:+,.0f}",
            "p50_latency_s_delta_vs_previous": "{:+.2f}",
            "cost_per_ticket_usd_delta_vs_previous": "${:+.5f}",
            "quality_delta_vs_previous": "{:+.2f}",
        }
    )
)

plot_df = summary.copy()
labels = plot_df["variant_label"].str.replace("Round ", "R", regex=False)

fig, axes = plt.subplots(1, 3, figsize=(16, 4))

axes[0].bar(labels, plot_df["mean_sync_tokens"], color="#4C78A8")
axes[0].set_title("Mean synchronous tokens")
axes[0].set_ylabel("sync tokens per ticket")
axes[0].tick_params(axis="x", rotation=30)

axes[1].bar(labels, plot_df["cost_per_ticket_usd"], color="#59A14F")
axes[1].set_title("Estimated cost")
axes[1].set_ylabel("USD per ticket")
axes[1].tick_params(axis="x", rotation=30)

axes[2].plot(labels, plot_df["mean_quality"], marker="o", color="#E15759")
axes[2].set_ylim(0, 1.0)
axes[2].set_title("Quality score")
axes[2].set_ylabel("score")
axes[2].tick_params(axis="x", rotation=30)

plt.tight_layout()
plt.show()

from live_api import (
    background_followup_request,
    live_config_for_ticket,
    run_live_support_ticket,
)

# Keep the allowed tools tied to the ticket being evaluated.
live_ticket = EVAL_SET[2]  # Order/policy lookup, then open a refund case.
live_config = live_config_for_ticket(live_ticket, "01_prompt_tool_context_controls")

if RUN_LIVE_API_CALLS:
    live_result = run_live_support_ticket(live_ticket, live_config, client=client)
    print(live_result["response_text"])
    display(pd.DataFrame([{k: v for k, v in live_result.items() if k not in {"response_text", "tool_results"}}]))
else:
    print("Dry-run mode. Set OPENAI_API_KEY and RUN_LIVE_API_CALLS=true to run a live Responses API ticket.")

Your refund request is eligible, and I’ve opened a return/refund case for order O-1003.

Next step: please use the return instructions from your order page or confirmation email to send the item back. Once the return is received and processed, your refund will be issued.

round1_request_example = {
    "model": "gpt-5.4",
    "instructions": CONTROLLED_PROMPT,
    "tools": SLIM_TOOLS,
    "tool_choice": allowed_tool_choice(["lookup_order", "lookup_policy"], mode="auto"),
    "reasoning": {"effort": "low"},
    "text": {"verbosity": "low"},
    "max_output_tokens": 350,
    "parallel_tool_calls": True,
    "truncation": "auto",
    "context_management": [{"type": "compaction", "compact_threshold": 20_000}],
    "input": [
        {
            "role": "user",
            "content": "My blender arrived cracked. Order O-1002. Can you replace it?",
        }
    ],
}

print(json.dumps(round1_request_example, indent=2)[:2400] + "\n...")

{
  "model": "gpt-5.4",
  "instructions": "Role: E-commerce support assistant.\n\nGoal: Resolve routine support tickets with the fewest necessary tool calls while preserving policy correctness.\n\nTool rules:\n- Use only tools required for the current decision.\n- Order status: order lookup only.\n- Damaged delivery or refund: order lookup plus the relevant policy.\n- Billing duplicate charge: order lookup plus billing policy, then escalate.\n- Account access with unverified identity: customer lookup plus account policy, then escalate.\n\nResponse rules:\n- Give the customer the outcome and next step.\n- Do not expose internal reasoning, raw tool data, audit notes, or policy text.\n- Keep the customer-facing answer under 120 words unless escalation legally requires more detail.",
  "tools": [
    {
      "type": "function",
      "name": "lookup_customer",
      "description": "Fetch minimal customer verification and support tier fields.",
      "parameters": {
        "type": "object",
        "properties": {
          "customer_id": {
            "type": "string"
          }
        },
        "required": [
          "customer_id"
        ],
        "additionalProperties": false
      },
      "strict": true
    },
    {
      "type": "function",
      "name": "lookup_order",
      "description": "Fetch order status, delivery age, payment status, and item value.",
      "parameters": {
        "type": "object",
        "properties": {
          "order_id": {
            "type": "string"
          }
        },
        "required": [
          "order_id"
        ],
        "additionalProperties": false
      },
      "strict": true
    },
    {
      "type": "function",
      "name": "lookup_policy",
      "description": "Fetch the policy needed for the current support decision.",
      "parameters": {
        "type": "object",
        "properties": {
          "topic": {
            "type": "string",
            "enum": [
              "shipping",
              "damaged_delivery",
              "refunds",
              "billing",
              "account_access"
            ]
          }
        },
        "required": [
          "topic"
        ],
        "additionalProperties": false
      },
      "strict": true
    },
    {
      "type": "function",
      "name": "create_refund_case",
      "description": "Open a refund or replacement case only after polic
...

round1_detail = traces[traces["variant"].isin(["00_bad_baseline", "01_prompt_tool_context_controls"])]
display(
    round1_detail[
        [
            "variant_label",
            "ticket_id",
            "intent",
            "tools",
            "action",
            "extra_tool_calls",
            "policy_compliant",
            "concise",
            "visible_output_tokens",
            "total_tokens",
            "latency_s",
            "cost_usd",
            "quality_score",
        ]
    ].style.format({"cost_usd": "${:.5f}", "quality_score": "{:.2f}", "latency_s": "{:.2f}"})
)

from live_api import TRIAGE_SCHEMA

print(json.dumps(TRIAGE_SCHEMA, indent=2))
# Optional: from live_api import live_triage_example
# live_triage_example(EVAL_SET[0]["message"], client=client)

{
  "type": "json_schema",
  "name": "support_triage",
  "strict": true,
  "schema": {
    "type": "object",
    "properties": {
      "intent": {
        "type": "string",
        "enum": [
          "order_status",
          "damaged_delivery",
          "refund_eligibility",
          "billing_issue",
          "account_access",
          "refund_dispute",
          "delivered_not_received",
          "high_value_damage"
        ]
      },
      "risk": {
        "type": "string",
        "enum": [
          "low",
          "medium",
          "high"
        ]
      },
      "needs_human": {
        "type": "boolean"
      },
      "order_id": {
        "type": [
          "string",
          "null"
        ]
      }
    },
    "required": [
      "intent",
      "risk",
      "needs_human",
      "order_id"
    ],
    "additionalProperties": false
  }
}

model_routing_view = traces[traces["variant"].isin(["01_prompt_tool_context_controls", "02_model_routing"])]
display(
    model_routing_view[
        [
            "variant_label",
            "ticket_id",
            "intent",
            "risk",
            "model",
            "routing_tokens",
            "total_tokens",
            "sync_cost_usd",
            "quality_score",
            "policy_compliant",
        ]
    ].style.format({"sync_cost_usd": "${:.5f}", "quality_score": "{:.2f}"})
)
