规模化 AI 智能体：在 GKE Autopilot 上部署 ADK 的分步指南

gcloud auth login

gcloud config set project [PROJECT_ID]

gcloud auth application-default login

export PROJECT_ID=$(gcloud config get-value project)
export REGION=us-central1
export CLUSTER_NAME=adk-cluster

gcloud container clusters create-auto $CLUSTER_NAME --region $REGION

mkdir adk-agent
cd adk-agent

uv init

uv add google-adk

uv run adk create weather_agent

weather_agent/
├── .env
├── __init__.py
└── agent.py

 from google.adk import Agent
# Define a simple tool for the agent
def get_weather(city: str) -> str:
    """Returns the current weather in a city."""
    return f"The weather in {city} is 90 degrees Fahrenheit and sunny."
# Initialize the agent with Vertex AI and Gemini
root_agent = Agent(
    name="weather_agent",
    model="gemini-2.5-pro",
    tools=[get_weather]
)

uv run adk web

.venv
.adk
__pycache__
*.pyc
.env

# Stage 1: Build the virtual environment
FROM python:3.10-slim AS builder

# Install uv
COPY --from=ghcr.io/astral-sh/uv:latest /uv /uvx /bin/

# Set working directory
WORKDIR /app

# Force uv to use the system Python and use copy instead of symlinks
ENV UV_PYTHON_PREFERENCE=only-system
ENV UV_LINK_MODE=copy
ENV UV_COMPILE_BYTECODE=1
ENV UV_PYTHON=/usr/local/bin/python3

# Install dependencies
# We copy only files needed for installation to maximize cache
COPY pyproject.toml uv.lock ./
# Note: We don't use --frozen yet as the host lock file might be slightly out of sync
# but sync will update it in the builder stage.
RUN uv sync --no-install-project --no-dev --no-cache

# Copy the agent code
COPY . .
# Sync the project itself
RUN uv sync --no-dev --no-cache

# Stage 2: Runtime image
FROM python:3.10-slim

WORKDIR /app

# Copy the pre-built environment from the builder
COPY --from=builder /app/.venv /app/.venv
# Copy the application code (including weather_agent folder)
COPY . .

# Add the environment to the PATH
ENV PATH="/app/.venv/bin:$PATH"
ENV PYTHONUNBUFFERED=1

# Run the ADK API server
# We point to the weather_agent folder
CMD ["adk", "api_server", ".", "--host", "0.0.0.0", "--port", "8080"]

# Create repository
gcloud artifacts repositories create adk-repo --repository-format=docker --location=$REGION

# Build and push
gcloud builds submit --tag $REGION-docker.pkg.dev/$PROJECT_ID/adk-repo/gke-agent:latest

gcloud iam service-accounts create adk-gke-sa

gcloud projects add-iam-policy-binding $PROJECT_ID \

    --member="serviceAccount:adk-gke-sa@$PROJECT_ID.iam.gserviceaccount.com" \
    --role="roles/aiplatform.user"

gcloud iam service-accounts add-iam-policy-binding adk-gke-sa@$PROJECT_ID.iam.gserviceaccount.com \
    --role="roles/iam.workloadIdentityUser" \
    --member="serviceAccount:$PROJECT_ID.svc.id.goog[default/adk-ksa]"

apiVersion: v1
kind: ServiceAccount
metadata:
  name: adk-ksa
  annotations:
    iam.gke.io/gcp-service-account: adk-gke-sa@$PROJECT_ID.iam.gserviceaccount.com
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: adk-agent
spec:
  replicas: 2
  selector:
    matchLabels:
      app: adk-agent
  template:
    metadata:
      labels:
        app: adk-agent
    spec:
      serviceAccountName: adk-ksa
      containers:
      - name: adk-agent
        image: $REGION-docker.pkg.dev/$PROJECT_ID/adk-repo/gke-agent:latest
        resources:
          requests:
            cpu: "500m"
            memory: "512Mi"
          limits:
            cpu: "1"
            memory: "1Gi"
        ports:
        - containerPort: 8080
---
apiVersion: v1
kind: Service
metadata:
  name: adk-service
spec:
  selector:
    app: adk-agent
  ports:
  - port: 80
    targetPort: 8080

kubectl apply -f deployment.yaml

kubectl get pods -w

kubectl port-forward svc/adk-service 8080:80

# Create a new session
curl -X POST http://localhost:8080/apps/weather_agent/users/u_123/sessions/s_123

# Run a message
curl -s -X POST http://localhost:8080/run \
-H "Content-Type: application/json" \
-d '{
"appName": "weather_agent",
"userId": "u_123",
"sessionId": "s_123",
"newMessage": {
    "role": "user",
    "parts": [{\
    "text": "Hey whats the weather in new york today"\
    }]
}
}' | jq .

{
    "sessionId": "s_123",
    "messages": [\
        {\
            "role": "assistant",\
            "parts": [\
                {\
                    "text": "The weather in New York today is sunny with a high of 90 degrees Fahrenheit."\
                }\
            ]\
        }\
    ]
}

gcloud compute addresses create adk-agent-ip --global
export AGENT_IP=$(gcloud compute addresses describe adk-agent-ip --global --format="value(address)")
echo "Your IP: $AGENT_IP"

gcloud compute ssl-certificates create adk-cert --domains adk.yourdomain.com --global

# Gateway: HTTPS load balancer with the managed certificate and static IP
apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: adk-gateway
spec:
  gatewayClassName: gke-l7-global-external-managed
  listeners:
  - name: https
    protocol: HTTPS
    port: 443
    tls:
      mode: Terminate
      options:
        networking.gke.io/pre-shared-certs: adk-cert
  addresses:
  - type: NamedAddress
    value: adk-agent-ip
---
# HTTPRoute: forward traffic to the ADK service
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: adk-route
spec:
  parentRefs:
  - name: adk-gateway
  hostnames:
  - "api.yourdomain.com"
  rules:
  - backendRefs:
    - name: adk-service
      port: 80
---
apiVersion: networking.gke.io/v1
kind: HealthCheckPolicy
metadata:
  name: adk-health
  namespace: default
spec:
  default:
    checkIntervalSec: 15
    timeoutSec: 5
    healthyThreshold: 1
    unhealthyThreshold: 2
    logConfig:
      enabled: false
    config:
      type: HTTP
      httpHealthCheck:
        port: 8080
        requestPath: /health
  targetRef:
    group: ""
    kind: Service
    name: adk-service

kubectl apply -f gateway.yaml

gcloud compute ssl-certificates describe adk-cert --global

# Create a new session
curl -X POST https://api.yourdomain.com/apps/weather_agent/users/u_124/sessions/s_124

# Run a message
curl -s -X POST https://api.yourdomain.com/run \
-H "Content-Type: application/json" \
-d '{
"appName": "weather_agent",
"userId": "u_124",
"sessionId": "s_124",
"newMessage": {
    "role": "user",
    "parts": [{\
    "text": "Hey whats the weather in new york today"\
    }]
}
}' | jq .

kubectl delete -f gateway.yaml
kubectl delete -f deployment.yaml
gcloud compute addresses delete adk-agent-ip --global
gcloud compute ssl-certificates delete adk-cert --global
gcloud container clusters delete $CLUSTER_NAME --region $REGION
gcloud artifacts repositories delete adk-repo --location $REGION
