把 Foundry IQ 知识库接到 Foundry 智能体服务

pip install "azure-ai-projects>=2.0.0" requests

import requests
from azure.identity import DefaultAzureCredential, get_bearer_token_provider

# Provide connection details
credential = DefaultAzureCredential()
project_resource_id = "{project_resource_id}" # e.g. /subscriptions/{subscription}/resourceGroups/{resource_group}/providers/Microsoft.CognitiveServices/accounts/{account_name}/projects/{project_name}
project_connection_name = "{project_connection_name}"
mcp_endpoint = "{search_service_endpoint}/knowledgebases/{knowledge_base_name}/mcp?api-version=2026-08-01-preview" # This endpoint enables the MCP connection between the agent and knowledge base

# Get bearer token for authentication
bearer_token_provider = get_bearer_token_provider(credential, "https://management.azure.com/.default")
headers = {
  "Authorization": f"Bearer {bearer_token_provider()}",
}

# Create project connection
response = requests.put(
  f"https://management.azure.com{project_resource_id}/connections/{project_connection_name}?api-version=2025-10-01-preview",
  headers = headers,
  json = {
    "name": project_connection_name,
    "type": "Microsoft.MachineLearningServices/workspaces/connections",
    "properties": {
      "authType": "ProjectManagedIdentity",
      "category": "RemoteTool",
      "target": mcp_endpoint,
      "isSharedToAll": True,
      "audience": "https://search.azure.com/",
      "metadata": { "ApiType": "Azure" }
    }
  }
)

response.raise_for_status()
print(f"Connection '{project_connection_name}' created or updated successfully.")

az account get-access-token --scope https://management.azure.com/.default --query accessToken -o tsv

PUT https://management.azure.com/{project_resource_id}/connections/{project_connection_name}?api-version=2025-10-01-preview
Authorization: Bearer {management_access_token}
Content-Type: application/json

{
  "name": "{project_connection_name}",
  "type": "Microsoft.MachineLearningServices/workspaces/connections",
  "properties": {
    "authType": "ProjectManagedIdentity",
    "category": "RemoteTool",
    "target": "{search_service_endpoint}/knowledgebases/{knowledge_base_name}/mcp?api-version=2026-08-01-preview", // This endpoint enables the MCP connection between the agent and knowledge base
    "isSharedToAll": true,
    "audience": "https://search.azure.com/",
    "metadata": {
      "ApiType": "Azure"
    }
  }
}

You are a helpful assistant.

Use the knowledge base tool to answer user questions.
If the knowledge base doesn't contain the answer, respond with "I don't know".

When you use information from the knowledge base, include citations to the retrieved sources.

from azure.ai.projects import AIProjectClient
from azure.ai.projects.models import PromptAgentDefinition, MCPTool
from azure.identity import DefaultAzureCredential

# Provide agent configuration details
credential = DefaultAzureCredential()
mcp_endpoint = "{search_service_endpoint}/knowledgebases/{knowledge_base_name}/mcp?api-version=2026-08-01-preview"
project_endpoint = "{project_endpoint}" # e.g. https://your-foundry-resource.services.ai.azure.com/api/projects/your-foundry-project
project_connection_name = "{project_connection_name}"
agent_name = "{agent_name}"
agent_model = "{deployed_LLM}" # e.g. gpt-4.1-mini

# Create project client
project_client = AIProjectClient(endpoint = project_endpoint, credential = credential)

# Define agent instructions (see "Optimize agent instructions" section for guidance)
instructions = """
You are a helpful assistant that must use the knowledge base to answer all the questions from user. You must never answer from your own knowledge under any circumstances.
Every answer must always provide annotations for using the MCP knowledge base tool and render them as: `【message_idx:search_idx†source_name】`
If you cannot find the answer in the provided knowledge base you must respond with "I don't know".
"""

# Create MCP tool with knowledge base connection
mcp_kb_tool = MCPTool(
    server_label = "knowledge-base",
    server_url = mcp_endpoint,
    require_approval = "never",
    allowed_tools = ["knowledge_base_retrieve"],
    project_connection_id = project_connection_name
)

# Create agent with MCP tool
agent = project_client.agents.create_version(
    agent_name = agent_name,
    definition = PromptAgentDefinition(
        model = agent_model,
        instructions = instructions,
        tools = [mcp_kb_tool]
    )
)

print(f"Agent '{agent_name}' created or updated successfully.")

az account get-access-token --scope https://ai.azure.com/.default --query accessToken -o tsv

POST {project_endpoint}/agents?api-version=v1
Authorization: Bearer {foundry_access_token}
Content-Type: application/json

{
  "name": "{agent_name}",
  "definition": {
    "model": "{deployed_llm}",
    "instructions": "\nYou are a helpful assistant that must use the knowledge base to answer all the questions from user. You must never answer from your own knowledge under any circumstances.\nEvery answer must always provide annotations for using the MCP knowledge base tool and render them as: `【message_idx:search_idx†source_name】`\nIf you cannot find the answer in the provided knowledge base you must respond with \"I don't know\".\n",
    "tools": [\
      {\
        "server_label": "knowledge-base",\
        "server_url": "{search_service_endpoint}/knowledgebases/{knowledge_base_name}/mcp?api-version=2026-08-01-preview",\
        "require_approval": "never",\
        "allowed_tools": [\
          "knowledge_base_retrieve"\
        ],\
        "project_connection_id": "{project_connection_name}",\
        "type": "mcp"\
      }\
    ],
    "kind": "prompt"
  }
}

using Azure.AI.Projects;
using Azure.AI.Projects.Agents;
using Azure.Identity;
using OpenAI.Responses;

#pragma warning disable AAIP001, OPENAI001

var mcpEndpoint = "{search_service_endpoint}/knowledgebases/{knowledge_base_name}/mcp?api-version=2026-05-01-preview";
var projectEndpoint = "{project_endpoint}"; // e.g. https://your-foundry-resource.services.ai.azure.com/api/projects/your-foundry-project
var projectConnectionName = "{project_connection_name}";
var agentName = "{agent_name}";
var agentModel = "gpt-4.1-mini";

AIProjectClient projectClient = new(new Uri(projectEndpoint), new DefaultAzureCredential());
var agentsClient = projectClient.AgentAdministrationClient;

// Define agent instructions (see "Optimize agent instructions" section for guidance).
var instructions = """
    You are a helpful assistant that must use the knowledge base to answer all the questions from user. You must never answer from your own knowledge under any circumstances.
    Every answer must always provide annotations for using the MCP knowledge base tool and render them as: `【message_idx:search_idx†source_name】`
    If you cannot find the answer in the provided knowledge base you must respond with "I don't know".
    """;

// Create an MCP tool that points at the knowledge base connection.
McpTool mcpKbTool = ResponseTool.CreateMcpTool(
    serverLabel: "knowledge-base",
    serverUri: new Uri(mcpEndpoint),
    allowedTools: new McpToolFilter { ToolNames = { "knowledge_base_retrieve" } },
    toolCallApprovalPolicy: new McpToolCallApprovalPolicy(GlobalMcpToolCallApprovalPolicy.NeverRequireApproval));
mcpKbTool.ProjectConnectionId = projectConnectionName;

// Create the agent with the MCP tool.
DeclarativeAgentDefinition definition = new(model: agentModel)
{
    Instructions = instructions,
    Tools = { mcpKbTool },
};
ProjectsAgentVersion agent = agentsClient.CreateAgentVersion(
    agentName: agentName,
    options: new ProjectsAgentVersionCreationOptions(definition));
Console.WriteLine($"Agent '{agentName}' created or updated successfully.");

from azure.ai.projects.models import StructuredInputDefinition

# Reference the token as a placeholder in the header
mcp_kb_tool = MCPTool(
    server_label = "knowledge-base",
    server_url = mcp_endpoint,
    require_approval = "never",
    allowed_tools = ["knowledge_base_retrieve"],
    project_connection_id = project_connection_name,
    headers = {
        "x-ms-query-source-authorization": "{{search_auth_token}}"
    }
)

# Declare the structured input so the caller can supply the token per request
agent = project_client.agents.create_version(
    agent_name = agent_name,
    definition = PromptAgentDefinition(
        model = agent_model,
        instructions = instructions,
        tools = [mcp_kb_tool],
        structured_inputs = {
            "search_auth_token": StructuredInputDefinition(
                description = "Per-user Azure AI Search bearer token",
                required = True,
                schema = {"type": "string"},
            )
        }
    )
)

print(f"Agent '{agent_name}' created or updated successfully.")

# Resolve an Azure AI Search token from the current credential (use a per-user token in production)
from azure.identity import get_bearer_token_provider

search_token = get_bearer_token_provider(credential, "https://search.azure.com/.default")()

openai_client = project_client.get_openai_client(agent_name=agent.name)
conversation = openai_client.conversations.create()

response = openai_client.responses.create(
    conversation = conversation.id,
    input = "{user_query}",
    extra_body = {
        "structured_inputs": {"search_auth_token": search_token},
    },
)

POST {project_endpoint}/agents?api-version=v1
Authorization: Bearer {foundry_access_token}
Content-Type: application/json

{
  "name": "{agent_name}",
  "definition": {
    "model": "{deployed_llm}",
    "instructions": "\nYou are a helpful assistant that must use the knowledge base to answer all the questions from user. You must never answer from your own knowledge under any circumstances.\nEvery answer must always provide annotations for using the MCP knowledge base tool and render them as: `【message_idx:search_idx†source_name】`\nIf you cannot find the answer in the provided knowledge base you must respond with \"I don't know\".\n",
    "tools": [\
      {\
        "server_label": "knowledge-base",\
        "server_url": "{search_service_endpoint}/knowledgebases/{knowledge_base_name}/mcp?api-version=2026-08-01-preview",\
        "require_approval": "never",\
        "allowed_tools": [\
          "knowledge_base_retrieve"\
        ],\
        "project_connection_id": "{project_connection_name}",\
        "type": "mcp",\
        "headers": {\
          "x-ms-query-source-authorization": "{{search_auth_token}}"\
        }\
      }\
    ],
    "structured_inputs": {
      "search_auth_token": {
        "description": "Per-user Azure AI Search bearer token",
        "required": true,
        "schema": { "type": "string" }
      }
    },
    "kind": "prompt"
  }
}

az account get-access-token --scope https://search.azure.com/.default --query accessToken --output tsv

POST {project_endpoint}/openai/v1/responses
Authorization: Bearer {foundry_access_token}
Content-Type: application/json

{
  "conversation": "{conversation_id}",
  "input": "{user_query}",
  "agent_reference": {
    "type": "agent_reference",
    "name": "{agent_name}"
  },
  "structured_inputs": {
    "search_auth_token": "{search_bearer_token}"
  }
}

# Get the OpenAI client for responses and conversations
openai_client = project_client.get_openai_client(agent_name=agent.name)

# Create conversation
conversation = openai_client.conversations.create()

# Send request to trigger the MCP tool
response = openai_client.responses.create(
    conversation = conversation.id,
    input = """
        Why do suburban belts display larger December brightening than urban cores even though absolute light levels are higher downtown?
        Why is the Phoenix nighttime street grid is so sharply visible from space, whereas large stretches of the interstate between midwestern cities remain comparatively dim?
    """,
)

print(f"Response: {response.output_text}")

Response: Suburban belts display larger December brightening than urban cores, even
though absolute light levels are higher downtown, primarily because holiday lights
increase most dramatically in the suburbs and outskirts of major cities. This is due
to more yard space and a prevalence of single-family homes in suburban areas...

The Phoenix nighttime street grid is sharply visible from space due to the city's
layout along a regular grid of city blocks and streets with extensive street lighting...

References:
- earth_at_night_508_page_174, earth_at_night_508_page_176 (Holiday lighting)
- earth_at_night_508_page_104, earth_at_night_508_page_105 (Phoenix grid visibility)

### Create conversation
POST {project_endpoint}/openai/v1/conversations
Authorization: Bearer {foundry_access_token}
Content-Type: application/json

{}

### Send request to trigger the MCP tool
POST {project_endpoint}/openai/v1/responses
Authorization: Bearer {foundry_access_token}
Content-Type: application/json

{
    "conversation": "{conversation_id}",
    "input": "\nWhy do suburban belts display larger December brightening than urban cores even though absolute light levels are higher downtown?\nWhy is the Phoenix nighttime street grid is so sharply visible from space, whereas large stretches of the interstate between midwestern cities remain comparatively dim?\n",
    "agent_reference": {
        "type": "agent_reference",
        "name": "{agent_name}"
    }
}

Suburban belts display larger December brightening in nighttime lights than urban
cores, primarily because suburban areas have more yard space and single-family homes
where holiday lighting decorations are more commonly used...

The Phoenix nighttime street grid is sharply visible due to the regular, planned
layout of city blocks with extensive street lighting, shopping centers, and
commercial properties along major streets...

References:
- earth_at_night_508_page_174_verbalized, earth_at_night_508_page_176_verbalized
- earth_at_night_508_page_104_verbalized, earth_at_night_508_page_105_verbalized

# Delete the agent
project_client.agents.delete_version(agent_name=agent.name, agent_version=agent.version)
print(f"Agent '{agent.name}' version '{agent.version}' deleted successfully.")

# Delete the project connection (Azure Resource Manager)
import requests
from azure.identity import DefaultAzureCredential, get_bearer_token_provider

credential = DefaultAzureCredential()
project_resource_id = "{project_resource_id}"
project_connection_name = "{project_connection_name}"

bearer_token_provider = get_bearer_token_provider(credential, "https://management.azure.com/.default")
headers = {"Authorization": f"Bearer {bearer_token_provider()}"}

response = requests.delete(
  f"https://management.azure.com{project_resource_id}/connections/{project_connection_name}?api-version=2025-10-01-preview",
  headers=headers,
)
response.raise_for_status()
print(f"Project connection '{project_connection_name}' deleted successfully.")

### Delete the agent
DELETE {project_endpoint}/agents/{agent_name}?api-version=v1
Authorization: Bearer {foundry_access_token}

### Delete the project connection
DELETE https://management.azure.com/{project_resource_id}/connections/{project_connection_name}?api-version=2025-10-01-preview
Authorization: Bearer {management_access_token}
